Wire & Cable
CONTROL CABLE 100' UNSHIELDED PVC JACKET 18 GAUGE 4 CONDUCTOR
XC2404
- PVC JACKET
- UL 70,000 BTU Vertical Tray Flame Test
- TEMPERATURE RATING -20 to 80 C
- Tinned Conductors provide Excellent Corrosion Resistance
- Assists Soldering Application
$318.75
$3.1875
$3.1875
GXL WIRE 1000' SPL 16 GAUGE, BLACK
XGXL16M2
- Cross-linked polyethylene wire.
- Vulcanized to obtain thermosetting insulation which will not melt when exposed to heat.
- For use at 60 volts or less.
- Rated at 125°C (257°F), low temperature rating of -40°C (-40°F).
- Meets SAE J1128 specifications.
$300.80
$0.3008
$0.3008
GXL WIRE 1000' SPL 16 GAUGE, WHITE
XGXL16M3
- Cross-linked polyethylene wire.
- Vulcanized to obtain thermosetting insulation which will not melt when exposed to heat.
- For use at 60 volts or less.
- Rated at 125°C (257°F), low temperature rating of -40°C (-40°F).
- Meets SAE J1128 specifications.
$350.00
$0.35
$0.35
THHN WIRE 600V 500' SPL 14 GAUGE, BLACK WITH WHITE STRIPE
XTHHN14D2/3
- Nylon jacket, PVC insulation, bare copper conductor.
- Rated 600 volts.
- Temperature rating of 90°C.
- Excellent resistance to abrasion, chemicals, gas and oil.
- Used as power, lighting and control wiring.
$362.50
$0.725
$0.725
UL/AWM 1015 WIRE 500' SPL 600V 10 GAUGE, BLACK TINNED
XUL10D2TC
- UL PVC insulated single conductor wire.
- Bare copper construction.
- Rated 600 volts.
- Temperature rating of 105°C (221°F).
- Meets UL, CSA, MTW, TEW, AWM 1015/1230/1345 specifications.
$900.00
$1.80
$1.80
LAMP CORD SPT-1 250' SPL 18 GAUGE, 2 CONDUCTOR, BLACK
ZC18XL2
- 18 gauge 2 conductor bonded wire.
- Black
- Rated at 300 volts, 105°s C.
- Thermoplastic insulation, with stranded copper conductors.
- Suitable for lamps, clocks, household fans and small appliances.
- The PVC insulation has ribs along one edge to provide polarity identification.
- UL listed and CSA approved.
- 250 foot spool
$186.25
$0.745
$0.745
UL/AWM 1015 WIRE 600V 500' SPL 18 GAUGE, BROWN
UL18D4
- UL PVC insulated single conductor wire.
- Bare copper construction.
- Rated 600 volts.
- Temperature rating of 105°C (221°F).
- Meets UL, CSA, MTW, TEW, AWM 1015/1230/1345 specifications.
- RoHS compliant.
- Multi-rated for internal wiring of appliances and equipment.
- 18 gauge, brown
- 500 foot spool
- 6-1/2" wide x 2-1/2" tall x 2" i.d. spool
$172.70
$0.3454
$0.3454
UL/AWM 1015 WIRE 600V 1000' SP 18 GAUGE, ORANGE
UL18M0
- UL PVC insulated single conductor wire.
- Bare copper construction.
- Rated 600 volts.
- Temperature rating of 105°C (221°F).
- Meets UL, CSA, MTW, TEW, AWM 1015/1230/1345 specifications.
- RoHS compliant.
- Multi-rated for internal wiring of appliances and equipment.
- 18 gauge, orange
- 1,000 foot spool
- 6-1/2" wide x 5" tall x 2" i.d. spool
$345.40
$0.3454
$0.3454
UL/AWM 1015 WIRE 600V 1000' SP 18 GAUGE, BROWN
UL18M4
- UL PVC insulated single conductor wire.
- Bare copper construction.
- Rated 600 volts.
- Temperature rating of 105°C (221°F).
- Meets UL, CSA, MTW, TEW, AWM 1015/1230/1345 specifications.
- RoHS compliant.
- Multi-rated for internal wiring of appliances and equipment.
- 18 gauge, brown
- 1,000 foot spool
- 6-1/2" wide x 5" tall x 2" i.d. spool
$345.40
$0.3454
$0.3454
UL/AWM 1015 WIRE 600V 1000' SP 18 GAUGE, PURPLE
UL18M9
- UL PVC insulated single conductor wire.
- Bare copper construction.
- Rated 600 volts.
- Temperature rating of 105°C (221°F).
- Meets UL, CSA, MTW, TEW, AWM 1015/1230/1345 specifications.
- RoHS compliant.
- Multi-rated for internal wiring of appliances and equipment.
- 18 gauge, purple
- 1,000 foot spool
- 6-1/2" wide x 5" tall x 2" i.d. spool
$304.50
$0.3045
$0.3045
BATTERY CABLE 100 FOOT ROLL 1/0 GAUGE, RED
X101BC
- Full gauge copper conductor.
- Tough, high temperature PVC insulation.
- For use at 60 volts or less.
- Meets SAE J1127 specifications.
- Temperature rating of 221° F.
- Recommended for connecting battery to switch, starter and ground.
- 1/0 gauge, red
- Nominal O.D. .550"
- 100 foot roll
$1,019.59
$10.1959
$10.1959
WELDING CABLE 100 FOOT ROLL 1/0 GAUGE, RED
X101WC
- High-strength, tear-resistant jacket.
- Excellent resistance to abrasion and impact.
- Superior flexibility.
- Flame resistant.
- Rated at 600 volts.
$1,043.14
$10.4314
$10.4314
PORTABLE-SJ/CORD 250' SPL 14 GAUGE, 2 CONDUCTOR, 300 V
X14X2SJ
- Synthetic rubber insulation with Thermoset jacket.
- Rated to 300 volts
- UL listed.
- CSA certified.
- OHSA acceptable.
- Flexible at low temperatures.
- Designed for hard usage with portable tools, equipment and motors.
- 14 gauge, 2 conductor
- 250 foot spool
$637.50
$2.55
$2.55
CONTROL CABLE UNSHIELDED PVC JACKET 16 GAUGE 4 CONDUCTOR
X16X4CC
- PVC JACKET
- UL 70,000 BTU Vertical Tray Flame Test
- TEMPERATURE RATING -20 to 80 C
- Tinned Conductors provide Excellent Corrosion Resistance
- Assists Soldering Application
$1,415.25
$2.8305
$2.8305
