Terminals
METRI-PACK CONNECTOR 150 SERIES, TPA 4 WAY, MALE
12047948
- 4 cavity, terminal position assurance.
- Nylon, black.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$28.91
$1.1564
$1.1564
METRI-PACK TERMINAL 150 SERIES, 20-16 GA, FEMALE
12048074
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
- Silicon bronze, tin plated.
- Blade width: 1.5mm
$70.00
$0.70
$0.70
METRI-PACK CABLE SEAL 150 SERIES, 20-16 GA, RED
12048086
- Cable seal for Metri-Pack 150 series.
- Silicone material, red in color.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$47.30
$0.473
$0.473
METRI-PACK CONNECTOR HOUSING 150 SERIES, 2 WAY, FEMALE
12052641
- 2 cavity, female connector assembly.
- Nylon, black.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$38.40
$3.84
$3.84
METRI-PACK CONNECTOR 150 SERIES, TPA 3 WAY, MALE
12052845
- 3 cavity, terminal position assurance.
- 6/6 nylon, natural.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$23.45
$0.938
$0.938
METRI-PACK CONNECTOR HOUSING 280 SERIES, 1 WAY, MALE
12065171
- 1 cavity, male connector.
- Nylon, black.
- 30 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
- High-current density in a small and compact design.
- Excellent resistance to temperature, chemicals and abrasion.
$26.397
$2.6397
$2.6397
METRI-PACK CONNECTOR 150 SERIES, TPA 6 WAY, MALE
12052850
- 6 cavity, terminal position assurance.
- Nylon, Gray.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$27.09
$1.0836
$1.0836
METRI-PACK CONNECTOR HOUSING 150 SERIES, 3 WAY, FEMALE
12110293
- 3 cavity, female connector assembly.
- Nylon, black.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$35.298
$3.5298
$3.5298
METRI-PACK CAVITY PLUG 150 SERIES, RED SILICONE
12059168
- Cavity plug for 150 series Metri-Pack.
- Silicone material, red in color.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$17.50
$0.70
$0.70
METRI-PACK TERMINAL 280 SERIES, 16-14 GA, FEMALE
12066214
- 30 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
- High-current density in a small and compact design.
- Excellent resistance to temperature, chemicals and abrasion.
- Brass, tin plated.
- Blade width: 2.8mm
$112.00
$1.12
$1.12
METRI-PACK CONNECTOR 280 SERIES, TPA 1 WAY LOCK
12065249
- 1 cavity, terminal position assurance.
- Nylon, black.
- 30 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
- High-current density in a small and compact design.
- Excellent resistance to temperature, chemicals and abrasion.
$28.28
$1.1312
$1.1312
METRI-PACK CONNECTOR HOUSING 280 SERIES, 1 WAY FEMALE
12065172
- 1 cavity, female connector assembly.
- Nylon, black.
- 30 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
- High-current density in a small and compact design.
- Excellent resistance to temperature, chemicals and abrasion.
$49.842
$4.9842
$4.9842
METRI-PACK CONNECTOR HOUSING 150 SERIES, 6 WAY, MALE
12124107
- 6 cavity, male connector.
- Nylon, black.
- 14 amps continuous maximum current rating.
- Low energy, low voltage capability.
- -40° C to 125° C temperature range.
$30.16
$3.016
$3.016
DEUTSCH PIN HOUSING 2 CAVITIES
DT042
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
- Accepts contact size 16 (14-20 gauge wire).
- Integrated latch for mating.
- 2 position housing that contains the pin contact.
$29.315
$2.9315
$2.9315
DEUTSCH PIN HOUSING 3 CAVITIES
DT043
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
- Accepts contact size 16 (14-20 gauge wire).
- Integrated latch for mating.
- 3 position housing that contains the pin contact.
$33.358
$3.3358
$3.3358
DEUTSCH SOCKET HOUSING 2 CAVITIES
DT062
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
- Accepts contact size 16 (14-20 gauge wire).
- Integrated latch for mating.
- 2 position housing that contains the socket contact.
$31.85
$3.185
$3.185
DEUTSCH SOCKET HOUSING 3 CAVITIES
DT063
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
- Accepts contact size 16 (14-20 gauge wire).
- Integrated latch for mating.
- 3 position housing that contains the socket contact.
$74.25
$7.425
$7.425
DEUTSCH SOCKET HOUSING 4 CAVITIES
DT064
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
- Accepts contact size 16 (14-20 gauge wire).
- Integrated latch for mating.
- 4 position housing that contains the socket contact.
$64.35
$6.435
$6.435
DEUTSCH PIN HOUSING 12 CAVITY
XDT0412
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
$138.125
$13.8125
$13.8125
DEUTSCH PIN HOUSING 3 CAVITY J1939
XDT04-3P-P007
- 3-Pin splitter, connector receptacle
- 3-Pin connectors offer a high performance, reliable and cost effective solution for the SAE 3 position
- Y receptacle is designed to be completely compatible with existing industry standard J1939 connectors
$248.675
$49.735
$49.735
DEUTSCH PIN HOUSING 8 CAVITY
XDT048
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
$142.375
$14.2375
$14.2375
DEUTSCH SOCKET HOUSING 12 CAVITY
XDT0612
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
$162.35
$16.235
$16.235
DEUTSCH SOCKET HOUSING 6 CAVITY
XDT066
- Environmentally sealed connectors designed specifically for cable to cable applications on the engine or transmission, under the hood, on the chassis or in the cab.
- Provide reliability and performance at the lowest cost.
- Thermoplastic housings and silicone seals are used to allow the connector to withstand conditions of extreme temperature and moisture.
- Dielectric Strength: 1500 volts minimum.
- Operative at temperatures from -67° F to 257° F.
$12.645
DEUTSCH SOCKET HOUSING 3 CAVITY ENHANCED SEAL RET., BLACK
XDT06-3S-P012
- Integral connector latch
- Designed specifically for cable-to-cable and cable-to-board applications in harsh environments
- Rugged thermoplastic housing
- -55°C to +125°C operating temperature range
- Available in 2, 3, 4, 6, 8, and 12 sizes
- Silicone seals
- Silicone seals
- Hand insertable/removable contacts
$6.05
